Technical Specifications
| Product Name | Fan Kit |
|---|---|
| Type Name | Extractor |
| Cased | Y |
| Number of Poles | 2P |
| Number of Speeds | 2 |
| Shape | Square |
| Motor Power | 7.4|8.4 W |
| Mounting | Surface |
| Ingress Protection | IPX4 |
| Air Extraction Rate m3/h | 54|76 M3/h |
| Reversible | N |
| c/w Light | N |
| c/w Duct | N |
| c/w Timer | N |
| c/w Humidistat | N |
| c/w Pullcord | N |
| Material | Plastic |
| Body Colour | White |
| Blade Colour | White |
| Overall Length | 178.5 mm |
| Overall Width | 178.5 mm |
| Overall Depth | 37.5 mm |
| Impeller Diameter | 98 mm |
| Number of Phases | Single |
| Voltage | 12 V |
| Frequency | 50 Hz |
| Maximum Sound Pressure Level | 22|34 Db |
