Technical Specifications
| Product Name | Cable |
|---|---|
| Type Name | Flexible |
| Number of Cores | 2 |
| Core Identification | Coloured |
| Earth Core | N |
| Conductor Material | Copper |
| Conductor Construction | Plain Annealed Flexible |
| Insulation Type | PVC |
| Armoured | N |
| Fire Resistant | N |
| Minimum Bending Radius | 19.2×31.2-22.8×37.8 |
| Flexibility class | 5 |
| Magnetic armour | N |
| Earthed Metallic Covering | N |
| Core Colours | |
| Outer Sheath Material | PVC |
| Outer Sheath Colour | White |
| Drum Length | 100 Metres |
| Cable Diameter | 3.2×5.2-3.8×6.3 mm |
| Conductor Size | 0.75 mm2 |
| Stranding Size | 24/0.2 mm |
| Minimum Temperature Rating | -15 Degrees C |
| Maximum Temperature Rating | 70 Degrees C |
| Voltage Rating | 300/300 V |
| Conforming Standard | |
| Unit Weight | 3.7 kg |
